QSFP56 to 2x100G QSFP56 PAM4 Breakout Active Optical

200G QSFP56 to 2x 100G QSFP56 Breakout Active Optical Cable for 200G Ethernet links over OM3/OM4/OM5 multimode fiber via a 200G connector on one side and two separate 100GbE connectors on the other side Provides connectivity between system units. This cable connects data signals from 4 MMF (Multimode Fiber) pairs on a single QSFP56 end to dual pairs on each QSFP56 multiport end. This active optical splitter cable complies with QSFP-MSA and 200GBASE-SR4 specifications.

Category： , ,

Warranty : 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.

Get a Quote
Contact Us
Product Number QSFP56-2QSFP56-AOC30M Vendor Name Walsun
Form Factor QSFP56 to 2x QSFP56 Max Data Rate 212.5Gb/s
Wavelength 850nm Cable Length 30m (98ft)
Modulation Format PAM4 Host Required FEC
Jacket Material LSZH Minimum Bend Radius 30mm
Cable Type MMF DDM Support Yes
Transmitter Type 850nm VCSEL Receiver Type PIN
Operating Case Temperature 0 to 70°C (32 to 158°F) Voltage Supply 3.3V
Protocols QSFP56 MSA, CMIS IEEE 802.3cd 200GBASE-SR4 Maximum Power < 5W (200G QSFP56), < 3W (100G QSFP56)
Connector Fiber Optic Cable Application 200GBASE-SR4 to 2x 100GBASE-SR2 Ethernet
